CLEAN FLAME BURNER NOZZLE #2

[Category : - Heating & Cooling]
[Viewed 682 times]

A combustion system comprises a discharge nozzle with concentric air and fuel orifices. A fuel conduit is coupled to each fuel orifice while an air conduit is coupled to each air orifice. The fuel and air only mixing with one another upon discharge. A supplemental air source supplies supplement air for combustion. An air deflector disk supports the discharge nozzle and a cylindrical blast tube surrounds the air deflector sleeve and the air deflector disk while an outlet end of the cylindrical blast tube supports a flame retention head. The deflector disk permits some combustion air to flow into the combustion chamber while redirecting a remaining portion of the supplement air. The flame retention head permits some of the supplement air to discharge into a burner box while redirecting the remaining supplement air radially inward through openings in the air deflector sleeve to assist with combustion of the fuel mixture. 1best when used in conjunction with Patent No. 9657038, which is also listed.

Financial information

We would like an outright sale, a license with royalties or another form of partnership.
We have done some marketing. See our website at Link

Patent publications:

US 9874349

Asking price:

Make an offer
